Product Description

Feature

Use within the string structure

Low equivalent series inductance and resistance

Having self-healing

Long life low temperature rise

White epoxy fill

No sense of structure, including Mylar tape

dV / dt value is high, RoHS Compliant


use

Absorption for GTO

Induction heating equipment

Welding inverter, UPS, EPS


characteristic

References IEC 61071 standard

Operating temperature range: -40C ~ 85C

Storage temperature range: -40C ~ 85C

Capacity range: 0.22to 5μF

Capacitance tolerance: ± 5%, ± 10%

Voltage Range: 300 --- 6000 Vdc


Test Data

Withstanding voltage: 2Un 10s

Loss tangent: 4.0 × 10-4CR≤1μF

6.0 × 10-4CR> 1μF Test Conditions: 100Hz 25C

Life expectancy: 100 000 hours

Insulation resistance: ≥100 000M CR≤0.33μF

C × Ri≥30000s CR> 0.33μF 100Vdc 25C


QQ20161014102025

QQ20161014105222

QQ20161014105227
