Item specifics
  • Brand Name: DFRobot
  • Type: Mini Desktop
  • Model Number: BB Black Package C
  • Modek Name: BeagleBone Black Package C
  • Processor: TI Sitara AM335x, 1GHz, 2000 MIPS
  • Feature 1: 1 GHz ARM Cortex -A8
  • Feature 2: SGX530 Graphics Engine
  • Feature 3: Programmable Real-Time Unit Subsystem
  • Memory: SDRAM: 512MB DDR3L 800MHZ
  • eMMC Flash: : Rev B: 2GB (discontinued) ;Rev C: 4GB (as of 2014.05.21)
  • Power management: TPS65217C PMIC used with a separate LDO to provide power to the system
Product Description

hello,
Your order is under $8, we unified send China Post Ordinary Small Packet Plus.
There is no tracking information, usually arrived in your country is 40-70 days, we don\'t accept the dispute,
If you don\'t wait, it is recommended that the purchase order is more than $8,


Your order is more than $8, we unified make arrangements for your China Post Registered Air Mail,
Have a tracking number query information, general arrived in your country is 25 to 50 days,
Please after receipt of the goods, the products in a 5 star evaluation, thank you for your understanding,

Debug Support: Optional Onboard 20-pin CTI JTAG, Serial Header

Welcomed to order these accessories of Beagle Bone Black !

BeagleBone Black ARM Cortex-A8 4GB eMMC Rev C BB Development Board+BB Black Expansion CAPE LCD Cape+4.3inch 480x272 LCD Display

BB Black/BeagleBone Black development/evaluation Package C


BB-Black

Overview

BeagleBone Black is an MSRP community-supported development platform for developers and hobbyists. Boot Linux in under 10 seconds and get started on development in less than 5 minutes with just a single USB cable.


Features

BB-Black on board resource

  • Processor: TI Sitara AM335x, 1GHz, 2000 MIPS
    • 1 GHz ARM Cortex-A8
    • SGX530 Graphics Engine
    • Programmable Real-Time Unit Subsystem
  • Memory
    • SDRAM: 512MB DDR3L 800MHZ
    • eMMC Flash:
      • Rev B: 2GB (discontinued)
      • Rev C: 4GB (as of 2014.05.21)
  • SD/MMC Connector for microSD
  • Power management: TPS65217C PMIC is used along with a separate LDO to provide power to the system
  • Debug Support: Optional Onboard 20-pin CTI JTAG, Serial Header
  • Power Source
    • miniUSB USB or DC Jack
    • 5VDC External Via Expansion Header
  • Connectivity
    • High speed USB 2.0 Client port: Access to USB0, Client mode via miniUSB
    • High Speed USB 2.0 Host port: Access to USB1, Type A Socket, 500mA LS/FS/HS
    • Serial Port: UART0 access via 6 pin 3.3V TTL Header. Header is populated
    • 10/100M Ethernet (RJ45)
  • User Input / Output
    • Reset Button
    • Boot Button
    • Power Button
    • LED power indicator
    • 4 user configurable LEDs
  • Video/Audio Interfaces
    • HDMI D type interface
    • LCD interface
    • Stereo audio over HDMI interface
  • Expansion Interfaces
    • LCD, UART, eMMC
    • ADC, I2C, SPI, PWM
  • Operating Power: 5V,0.35A
  • Board Size: 3.4 x 2.1

Photos


What\\\'s on the LCD CAPE (4.3inch)

BB Black Expansion CAPE on board resource

  1. BB_BLACK connector : for connecting BB Black
  2. 4.3inch LCD interface : for connecting 4.3inch resistive touchscreen LCD
  3. DEBUG interface : BB Black debug interface, for connecting serial modules
  4. BOOT selection button : Boot from TF card

LCD CAPE (4.3inch) Photos

BB Black Expansion CAPE
LCD CAPE (4.3inch) BB Black Expansion CAPE
BB Black Expansion CAPE
LCD CAPE (4.3inch) BB Black Expansion CAPE back view
BB Black Expansion CAPE
LCD CAPE (4.3inch) BB Black Expansion CAPE
BB Black Expansion CAPE
Connecting with BB Black and 4.3inch LCD

Package Contains

  1. BB Black x 1
  2. LCD CAPE (4.3inch) x 1
  3. 4.3inch 480x272 Touch LCD (A) x 1
  4. USB to TTL 4-pin Wire × 1
  5. Power Adapter US Standard 5V 2A 5.5/2.1mm × 1
  6. USB type A plug to mini-B plug cable x 1
  7. 40-pin FFC 0.5 150mm (opposite sides contact) x1
  8. 4.3inch LCD screws pack x 1
1
2
3
4
5
6
7
8

Recommended Items

To get more expandability, you may also need :

  • RS485 and CAN interfaces provided : RS485 CAN CAPE
  • Arduino supported : CAPE for Arduino
